Measurement of the instantaneous values of over 130 measured variables (U, I, P, Q, S, PF, PA, f, φ, THD, MD, energy consumption, energy costs by tariff, etc.)
Measurement of 40 minimum and maximum values in different time periods
Serial RS232, RS485 or Ethernet interface
MODBUS and DNP3 communication protocol
MMC card for device setting and upgrades
Up to 4 inputs or outputs (analogue output, pulse output, alarm output, tare input)
Additional serial interface (COM 2)
Universal auxiliary power supply for AC/DC or AC auxiliary power supply for rated voltages
LCD graphic display; 128 x 64 pixels with backlighting
Automatic range determination of rated current and rated voltage (up to max. 12.5 A / 750 V)
Adjustable tariff clock for calculating the cost of energy consumption in any currency
User-friendly MiQen PC software
