Measurement of instantaneous values of more than 60 input quantities (U, I, P, Q, S, PF, PA, f, φ, THD, MD …) - (nur MC330)
Automatic range selection for the rated current (max. 12.5A) and optionally for the voltage
Accuracy class 0.5 (for U, I, P), 1 (active energy)
Frequency range from 16 Hz to 400 Hz
Up to 2 tariff inputs (option)
Up to 2 pulse or relay outputs (option)
AC auxiliary voltage or (optional) universal auxiliary voltage (AC/DC)
Graphic LC display (128 x 64 dots with backlight)
Configurable measured value display
13 selectable menu languages
Optional serial interface with max. 115,200 bit/s (RS 485 or RS 232)
Support of the MODBUS protocol
User-friendly MiQen PC software for unit setting and measured value display
